Architect: Stack Interiors

Location：Auckland,, New Zealand

Project Year: 2021Category：Offices

What was the brief?

Mercedes Benz NZ relocation of their head office was an opportunity to support changes in the business structure and provided the ability to adapt to new workplace strategies. Mercedes reduced their office footprint but created a new vision in the form of an agile office that supports the business in working as one team.

Rebecca Swan

The Staff Café provides amenities to staff and visitors and also supports both team and informal meetings. Workspaces provide agile work settings that allow teams to come together to work and collaborate within the office and with remote teams. Alternative work settings support quiet concentrated work, collaboration, digital and in-person meetings. Seamless technology was integral to the workspace and for connecting with customers and remote staff.

Rebecca Swan

What were the key challenges / material selection?

STACK created a sense of arrival for visitors and an opportunity for brand presentation and incorporation in the fit-out. Subtle details represent Mercedes Benz branding that can be seen throughout the space.

The colour and material palette feature concrete tones, blackened steel, leather, and wood, suggesting the luxury of a Mercedes-Benz automobile. The design captivates, fascinates, and provides a unique experience for staff and visitor.

Rebecca SwanModern Luxury

– timeless beauty, a combination of high-grade technology and craftsmanship. Black and silver were used as Mercedes main brand colours, while complemented with a warm tonal range of natural materials, such as leather, and wood, to give a feeling of being approachable and sophisticated. Modern graphic elements were carefully selected to support the brand identity.

Rebecca SwanIntelligent –

Innovative solutions and digital comfort are seamlessly integrated. Wireless Audio Visual and Internet connectivity helped transform getting A to B into its simplest form. The main goal of NO cables hanging around was successfully achieved. The Café banquette and window leaner joinery were equipped with power and USB chargers for easy access.

Rebecca SwanEmotional –

A welcoming ambiance was created for staff and invited visitors alike, that provides flexibility and consistency with the desired aesthetic. The Mercedes-Benz STAR was placed at the point of entry, mounted on a black feature wall. This wing-like wall with a subtle black texture borrowing Mercedes car aesthetics and detailing. The Café functions sit behind this wall and provide a space for casual meetings, collaboration, and eating. It was positioned to make the most of the views that can be appreciated by all.

Rebecca Swan

Rebecca Swan

Rebecca Swan

Material Used :Flooring:Accent Carpet

Supplier: INZIDE

Specification: Equal Measure Collection

Colour: 104561 Hill Street

Colour: 104569 Hill Ave

Colour: 104577 Hill Blvd.

Tufted Sheared

100% Recycled Content Nylon

Aquafil / 100% Solution Dyed / Protekt Soil/Stain Protection / Intersept Preservative Protection

General CarpetSupplier: INZIDE

Specification: Equal Measure Collection

Colour: 104580 Union Blvd.

Colour: 104572 Union Ave

Colour: 104564 Union Street

Tufted Sheared

100% Recycled Content Nylon

Aquafil / 100% Solution Dyed / Protekt Soil/Stain Protection / Intersept Preservative Protection

Anti-static vinyl

Supplier: JACOBSEN’S

Specification: TarkettColour: 96712Granit SD

Static Dissipative homogeneous vinyl flooring

Commercial: 340 / Surface Treatment: iQ PUR

Concrete FlooringSupplier: MegafloorExposure: UrbanFinish: PremiumSheen: GlossPaintGeneral PaintSupplier: Dulux

Specification: 6721D Dulux Painting Interior

Colour: White on White

Gloss Level: Low Sheen

Coating Type: Water based

System: DuSpec NZ_SD10687

Fire Rating: Group Number 1-S, Report Number 5054, NZBC C/VM2 A1.5

Accent PaintSupplier: Dulux

Specification: 6721D Dulux Painting Interior

Colour: Grey Daze

Colour: Stone Master

Colour: Grey Encounter

Gloss Level: Low Sheen

Coating Type: Water based

System: DuSpec NZ_SD10687

Fire Rating: Group Number 1-S, Report Number 5054, NZBC C/VM2 A1.5

Door/Frame Paint

Supplier: Dulux

Specification: 6721D Dulux Painting Interior

Colour: White on White

Gloss Level: Low Sheen

Coating Type: Water based

System: DuSpec NZ_SD10695

Fire Rating: Group Number 1-S, Report Number 5054, NZBC C/VM2 A1.5

Ceiling PaintSupplier: Dulux

Specification: 6721D Dulux Painting Interior

Colour: Lexicon Quarter

Gloss Level: Low Sheen

Coating Type: Water based

System: DuSpec NZ_SD10695

Fire Rating: Group Number 1-S, Report Number 5054, NZBC C/VM2 A1.5

Skirting PaintSupplier: Dulux

Specification: 6721D Dulux Painting Interior

Colour: TeKuiti NZ10H1

Gloss Level: Low Sheen

Coating Type: Water based

System: DuSpec NZ_SD08884

Fire Rating: Group Number 1-S, Report Number 5054, NZBC C/VM2 A1.5

Powder CoatingSupplier: DuluxMannex Finish

Colour: 9159056Z Mannex Matt Black

Colour: 9151171Z Mannex Appliance White

Wallpaper

Supplier: James Dunlop

Specification: Olea W/Panel 7484 by Casamance

Collection: ManielleCode: 50116-101Code: 50116-102

Composition: Non Woven Heavy Vinyl

Horizontal Pattern repeat: 204.0cm

Vertical Pattern repeat: 300.0cm

Width: 68.0cm

Roll length: 9.0m

Origin: ItalyAcoustic PanelSupplier: AUTEXSpecification: VISAGE

Composition: 100% Polyester Fibre (PET)R

Felt

Composition: 100% Polyester Fibre (PET)Drop width: 1.3m x 25mTolerance: (+5mm)Thickness: 4mm

Weight: 380gsm

Direct glue fixed into panels

Fire Rating Classification: Group 1-S

Laminate:Supplier: Acero Wilson Art

Specification: Brushed Alu – Satin Finish

3952 - S

High Pressure Laminate

Size: 3660mm x 1530mm

Substrate Thickness: 12mm

Faces: 1 side

Supplier: Hallmark Group

Specification: Purematte

High Pressure Laminate

Size: 2440mm x 1220mm

Substrate Thickness: 12mm

Faces: 1 sideSupplier: LAMINEX

Specification: Laminex Magnetic

Laminate Glossy White

Low Pressure Laminate

Size: 2400mm x 1220mm

(cut-out: please follow details)Substrate Thickness: 12mm

Substrate Type: MDF Standard

Faces: 1 sideSupplier: LAMINEX

Specification: Formica Melteca

Low Pressure Laminate

Size: 2400mm x 1220mm

Substrate Thickness: 18mm

Substrate Type: MDF Standard

Faces: 1 side

Supplier: Prime Panels NZ

Specification: Prime Melamine

Low Pressure Laminate

Size: 2400mm x 1220mm

Substrate Thickness: 12mm

Substrate Type: MDF FR Black

Faces: 1 sideSupplier: LAMINEX

Specification: Laminated Panels Range

Size: 2440mm x 1220mm

Thickness: 18mm

Substrate Type: MDF FR Black

Faces: 1 sideSupplier: LAMINEX

Specification: Laminated Panels Range

Size: 2440mm x 1220mm

Thickness: 18mm

Substrate Type: MDF FR Black

Faces: 1 sideSupplier: LAMINEXSpecification: Snowdrift

Substrate Type: Standard MDF

Faces: 1 side

Edge Detail: 1mm standard matching edging

Stainless Steel / Aluminum

Supplier: Wilsonart

Specification: Hairline finish

Anodisedaluminum

Thickness: .025 / 3mm (inserts)Acrylic Solid Surface

Supplier: APTSpecification: CorianOrganic Collection

Size: 12mm x 3658 x 760

Metal Mesh

Supplier: Locker NZ

Specification: Style 19mm x 30mm

3mm thick67-74% Open Area

Powder Coat in Selected Colour

Mosaic Tile

Supplier: European Ceramics

Specification: PorcelainFrames AnthraciteFinish: Gloss

Size: 300mm x 300mm x 8mm

UpholsterySupplier: WarwickSpecification: EastwoodWidth: 140cm

Pattern Rpt: H Plain V Plain

Suitability: Heavy Commercial

Composition: 100% PolyesterFibre Content: 32Care: 3

Supplier: James Dunlop

Specification: Foster Halo

Width: 145cm

Pattern Rpt: Plain

Suitability: Heavy Commercial

Composition: 100% PolyesterRailroaded: MultiSupplier: Maharam

Specification: Maharam - Merit

Width: 137cm

Finish: Water Repellent

Bolt Size: 45 yards

Origin: USA

Performance: 1000,000 double rubs wyzenbeek

Characteristics: 76% Post-consumer recycled polyester, 24% polyester
